Saw Blade diameters: ф100—ф500mm
Polishing type: sandbelt polishing
Belt grit: 150# 180# 280#
Working air pressure:≥0.5MPA
●Used for carbide and diamond saw blade polishing.
●Full automatic PLC control, simple operation, clear data setting.
●Adopt coolant for polishing, reduce heat when polishing which ensure the flatness will not be affected.
●Polishing speed and times can be set.
●Automatically polish and feed, there is delay function when polish the edge to make sure the line clear. One worker can operate several machines which improve the efficiency.
|
NO |
Items |
Description |
|
1 |
Saw Blade diameters |
ф100—ф500mm |
|
2 |
Arbor size |
ф10—ф50mm (Special specifications can be customized ) |
|
3 |
Polishing speed |
Class production about 1500 pieces |
|
4 |
Belt size |
1230x34mm |
|
5 |
Belt grit |
150# 180# 280# |
|
6 |
Working air pressure |
≥0.5MPA |
|
7 |
Total power |
10.5KW |
|
8 |
Voltage |
380V, 50HZ, 3 Phase |
|
9 |
Weight |
730KG |
|
10 |
Dimensions |
1510X1150X1910mm |
